VZLG series Vertical Drying Oven
VZLG series Vertical Drying Oven - Image 2

VZLG series Vertical Drying Oven

$560.00

Drying oven,Blast drying oven,Hot air oven

99 in stock

Submit an Inquiry
Email Us
SKU: VZLG-9030/A;VZLG-9070/A;VZLG-9140/A;VZLG-9240/A;VZLG-9420/A;VZLG-9620/A;VZLG-9640/A;VZLG-9920/A
Category:
品牌：
For more detailed specifications, please visit the official website.

Description

Model VZLG-9030/A VZLG-9070/A VZLG-9140/A VZLG-9240/A VZLG-9420/A VZLG-9620/A VZLG-9640/A VZLG-9920/A
Workroom size

(W*D*H)mm

 340*320*320 400*350*500 550*450*550 500*600*750 600*550*1300 800*600*1300 800*800*1000 1000*600*1600

Outer Size

(W*D*H)mm

 490*500*560 550*530*760 700*650*810 650*800*1010 750*750*1560 950*800*1560 950*1000*1430 1150*800*1860
Average Power(W) 800 1600 1900 2400 3600 4100 4100 5300

N.W./

G.W.

 40kg/50kg 59kg/65kg 77kg/85kg 109kg/125kg 188kg/208kg 216kg/240kg 195kg/215kg 318kg/350kg
Shelves 2PCS 3PCS 4PCS
Power supply AC220V±10%/50Hz±2% AC380V±10%/50Hz±2%
Temperature control range RT+10~250℃/RT+10~300℃
Temperature resolution 0.1℃
Temperature fluctuations ±0.5℃
Temperature uniformity ±2%℃
External material high quality cold rolled steel
Internal material 304 stainless steel
  1. Temperature control system adopts microcomputer control technology.
  2. High quality nickel-chromium alloy heater with low power attenuation.
  3. The unique air duct design allows the airflow to circulate in a specified direction, and the temperature uniformity in the working chamber changes little.
  4. Insulation material is made of high quality high temperature resistant glass fiber.
  5. It is made of 1.0 thick steel plate full-welded and polished, and the surface is spray-coated. The cabinet sprays 5% salt spray test for up to 500 hours (national standard 48 hours), with superior corrosion resistance.
  6. The inner liner is made of high quality SUS304 stainless steel plate with a thickness of 1.0mm.
  7. The product uses liquid crystal display.
  8. Shelf grid height can be adjusted.
  9. The door has a double tempered glass observation window for users’ observation.
  10. Nano-material door seals make the machine performance superior.
  11. High temperature resistant fan for longer life.
  12. Timing range: 0-9999 minutes.
  13. Products passed ROHS environmental certification, CE certification.
  14. Upgradeable networking or program control.(Optional)
