EJ-N435 series N2 cabinet

Description

Applications:
It can be used for storage of ICs, BGAs, precision electronic components, special chemicals, semiconductor devices, optical electronic devices, printed circuit boards, optical films and lenses, precision instruments and meters. Complies with IPC/JEDEC J-STD-033D standards for humidity, ensuring ideal storage of even high-value IC packages.
Product Features :
1.The cabinet is made of 1mm and 1.2mm high-quality steel plates. It has multiple reinforcement structures, good load-bearing performance, overlapping structure design and good sealing performance.
2.The surface of the cabinet is treated by 18-step orange-peel paint, which has highly corrosion resistance.
3.Anti-static paint used in anti-static surface treatment, static resistance value is 106-108 ohms. It has beautiful appearance and strong corrosion resistance.
4.The door is set with 3.2mm high strength tempered glass. The flat pressurizing handle lock is integrated and has anti-theft function.
5.The base is equipped with movable brake wheels for easy movement and fixing. The anti-static model casters are anti-static casters.
6.Ultrahigh brightness LED display, temperature and humidity sensor using the original American brand honeywell, with temperature and humidity independent display, has long service life. Humidity can be set and has a memory function, no need to set after power off.
7.Equipped with a nitrogen saving device, when the humidity in the box reaches to the set value, the system will automatically cut off the nitrogen supply. When the set value is exceeded, the system will automatically open the nitrogen supply. Compared with other direct nitrogen filling models in the market, it can save 70% nitrogen consumption. Greatly reduce the cost of use.
8.A multi-point gas supply system is used. Nitrogen gas is flushed into the tank through more than 30 small holes, and the nitrogen in the tank is well distributed. It avoids the dead corner caused by ordinary single point air supply.
9.It is used for the storage of moisture-sensitive materials, moisture-proof storage, and storage of materials with particularly sensitive humidity such as IC. Anti-static paint can be purchased.
10.We have CE certification and RoHS certification for this product.
